Lynxmotion SES-V2 Conveyor HD Kit w/ LSS-HT1

LynxmotionSKU: RB-Lyn-1082
Manufacturer #: LSS-CONV-HD-KT

Price  :
Sale price €304,22

Tax included Shipping calculated at checkout

Stock  :
Only 2 units left

Payments and Security

Apple Pay Mastercard PayPal Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Description

Kit Version

  • 49x 3” wide track segments
  • 49x rugged polypropylene axles & hardware
  • 1x Aluminum extrusion 80 x 20 x 500mm
  • 8x Aluminum extrusion 20 x 20 x 100mm
  • 8x Connection corner bracket
  • Composite G10 frame plates
  • 4x Sprockets
  • 2x Aluminum shafts
  • 3x Aluminum hubs
  • 1x Aluminum hub to SES adapter

What’s Needed - Lynxmotion Smart Servo Configuration

  • 1x Lynxmotion HT1 Smart Servo Motor (included in bundle)
  • 1x 12V Lynxmotion Power Supply**
  • 1x Electronics (LSS Adapter, LSS 2RC recommended)**

What’s Needed - spur gear motor configuration

  • 1x Spur gear motor (see note regarding mounting requirements*)
  • Power supply (ideally match the nominal voltage of the motor)
  • DC Motor controller (compatible with spur gear motor)

** If used with a Lynxmotion SES V2 robotic arm, the LSS Adapter and LSS 12V power supply included with the arm can be used to power and control the conveyor and therefore do not need to be purchased separately.

Size

  • Length (overall): 658 mm / 26 in
  • Length (working range): 596 mm / 23.5 in
  • Width (overall): 288mm / 11.34 in
  • Width ( track): 76 mm / 3 in
  • Height (overall): 138mm / 5.4 in
  • Belt pitch: 27 mm / 1.07 in

Conveyor Dimensions:

LSS Conveyor HD - Dimensions

Track Dimensions:

Lynxmotion (LSS) - 650mm Conveyor Kit - Click to Enlarge

Gear Motor Mounting Dimensions:

Lynxmotion (LSS) - 650mm Conveyor Kit - Click to Enlarge

  • Sprocket driven and robust friction top track segments
  • Track segments made of polypropylene and rubber shore A (hardness of 45)
  • Track pitch is 1.07'', and width is 3''
  • Actuator mount for Lynxmotion Smart Servo (LSS) or spur gear motor*
  • Aluminum and G10 frame / structure

* Mounting pattern for spur gear motor is specific (see Lynxmotion wiki page for details) and requires a 6mm to 6mm shaft coupler (sold separately).
